RFID Cards & Fobs for eSSL, ZKTeco & Door Readers: Printing & Compatibility

Published 4 Oct 2026Updated 12 Nov 202613 min read

Written and maintained by the RFID team at Identium Tech Solutions Pvt Ltd, New Delhi (India RFID Store).

Prices checked on 12 Nov 2026 against the catalogue.

RFID Cards & Fobs for eSSL, ZKTeco & Door Readers: Printing & Compatibility

Short answer: Find out what your reader reads before you order cards or key fobs. eSSL and ZKTeco terminals take 125 kHz EM cards, which their spec sheets call "ID card", or 13.56 MHz MIFARE cards, called "IC card", and several models ship with either module or an HID one. Tap-test two samples, note the number the software shows, then fix chip, numbering, encoding and artwork.

How do you find out which card your eSSL, ZKTeco or door reader reads?

A card made for one frequency is invisible to a reader built for another. 125 kHz (LF) proximity cards are the long-standing attendance and door card. 13.56 MHz (HF) covers MIFARE and NFC. UHF cards, read from a metre or more, belong at barriers and vehicle gates, where Indian readers use the licence-exempt 865–868 MHz band under G.S.R. 853(E). Check in this order:

  1. Read the spec sheet in the vendor's words. eSSL's page for its AiFace-Mars terminal lists "125KHz ID card(EM) / 13.56MHz IC card (MF)" modules, with the ID card standard and the IC card optional. Its USB enrolment readers come as the CR10E (125 kHz proximity) and CR10M (13.56 MHz MIFARE). Read "ID" or "EM" as 125 kHz and "IC" or "MF" as 13.56 MHz; treat a model suffix such as E or M as a hint, not proof.
  2. Check the unit, not the model. ZKTeco India lists the card function as optional on the K40 Pro (ID or IC card) and the IN01-A (ID, IC or HID). Two terminals with the same model name can need different cards, so check the menu, invoice or installer's records for yours.
  3. Tap-test two known samples. Present one 125 kHz and one 13.56 MHz card at the enrolment screen; the one that returns a number gives the frequency. Ask for one of each through our sample request page.
  4. Hold an existing card to a phone. An NFC-enabled Android phone with a tag-reading app detects most 13.56 MHz cards and cannot see 125 kHz cards, so silence points to LF.
  5. Look for HID. eSSL's AiFace-Mars+HID verifies by face, HID card or password. Such models need HID-format credentials, usually supplied through your integrator; do not assume a generic card will read.
What the reader or spec sheet saysFrequencyCard to printShop
"ID card", "EM", "Proximity"125 kHzEM4200/TK4100 read-only, T5577 writable, or LF keyfobLF cards, LF keyfob
"IC card", "MF", "Mifare"13.56 MHzMIFARE, usually Classic 1KHF attendance cards
"NFC", or phones tap the card13.56 MHzNTAG NFC cardNFC cards
Both reader types on one site125 kHz + 13.56 MHzLF-HF dual-frequencyLF-HF dual-frequency card
"HID card", "+HID" modelHID formatHID credentials in your system's formatAsk your integrator
Gate read at a metre or moreUHF, 865–868 MHzUHF card, or HF+UHF hybridPrinted UHF cards, hybrid cards

Brand names here describe compatibility only and belong to their owners. Hardware revisions change, so the tap test outranks any table.

Which cards and fobs fit which machine?

Once you know the frequency, these are the cards, key fobs and enrolment readers in our catalogue for each machine type. List prices are before GST.

Machine type (what the spec sheet says)ProductFormList priceMinimum order
125 kHz: "ID card", "EM", proximity125 kHz LF card, plain white PVCCard₹10 + GST500 pcs
125 kHz: "ID card", "EM", proximityLF keyfob, 53 × 37 mm, IP67Key fob₹20 + GST500 pcs
125 kHz: "ID card", "EM", proximityLF token, 30 mm ABS (EM4100 or T5577)Token₹25 + GST500 pcs
125 kHz: "ID card", "EM", proximityLF USB desktop reader IDTS-LFPPREnrolment reader (USB)₹1,500 + GST1 unit
13.56 MHz: "IC card", "MF", MIFAREHF card, plain PVCCard₹10 + GST500 pcs
13.56 MHz: "IC card", "MF", MIFARERKT keyfob (MIFARE Classic 1K on the HF version)Key fob₹20 + GST500 pcs
13.56 MHz: "IC card", "MF", MIFAREHF desktop reader HRD20 (USB)Enrolment reader (USB)₹2,000 + GST1 unit
13.56 MHz with phone tap ("NFC")NFC card (NTAG, MIFARE Classic or DESFire options)Card₹20 + GST500 pcs
Both on one site (125 kHz + 13.56 MHz)LF + HF dual-frequency cardCard₹28 + GST500 pcs
Either frequency, printed photo IDPrinted RFID ID card, 760 micronsPrinted card₹30 + GST500 pcs
Either frequency, portable checkPortable USB reader IDTS-HRP60Reader (USB)₹2,800 + GST1 unit
Either frequency, networked pointIP reader IDTS-HRW560 with Wi-Fi and PoEReader (network)₹10,000 + GST1 unit
UHF gate or boom barrier (865–868 MHz)UHF card IDTS-IDC62 (CR80, 0.9 mm)Card₹20 + GST500 pcs
UHF gate or boom barrier (865–868 MHz)Plain UHF card IDTS-IDC3D (printable)Card₹25 + GST500 pcs
"HID card", "+HID" modelsHID-format credentials, through your integratorCard or fob——

The RKT keyfob, the HRP60 and the HRW560 are each supplied in one frequency, so state 125 kHz or 13.56 MHz when you order.

Which chip should you print on?

  • EM4200 or TK4100 (125 kHz, read-only). A factory-set ID that cannot be changed, so you either print that ID or link the card to a person at enrolment.
  • T5577 (125 kHz, writable). Can be programmed with a chosen ID in EM format to match an existing numbering plan. The same property means it can be used to copy an EM card.
  • MIFARE Classic 1K (13.56 MHz). Many attendance systems use only its UID (eSSL's CR10M enrolment reader reads the card number only); the sector memory serves canteen wallets, hotel locks and some access systems.
  • NTAG (13.56 MHz NFC). Phone-readable, for NFC business cards and tap-to-open links. Some 13.56 MHz terminals read an NTAG UID, but test first.
  • Dual-frequency LF-HF. Two chips in one CR80 body, for sites running both reader types or moving between them.

How are RFID cards printed, and what changes the cost?

  • Pre-printed (offset or screen) before lamination. Artwork goes on PVC sheets, the chip inlay is laminated between them, and cards are punched out. Best for one design in volume; set-up makes very short runs dear per card.
  • Digital printing at the factory. Suits short runs and variable data: names, photos, QR codes, numbers. Our printed card listings offer full-colour offset or digital printing, gloss or matt.
  • Your own direct-to-card printer. A desktop ID card printer adds names and photos to blank white cards as staff join. ISO/IEC 7810 sets a nominal card thickness of 0.76 mm; our printed RFID ID card is a CR80 card listed at 760 microns.
  • Numbering in a separate pass, often laser-engraved or printed after the main design.

Thick "clamshell" cards are a different product: ZKTeco India describes its ID Thick Card as an ABS shell with a PVC cover label, so check a thick card's stated thickness against your printer's supported range. Slot punching is the other trap. Punch only cards built for it and fix the punch position at order time, because a slot through the antenna can stop the card working.

What moves the price per card:

  • The chip: dual-frequency and hybrid cards cost more than single-chip cards.
  • One printed side or two, and variable data on each card.
  • Encoding or reading every chip.
  • Finishes such as a signature strip, magnetic stripe or hologram, and slot punching.
  • Quantity, which spreads proofing and set-up across more cards.

How should cards be numbered so the printed number matches the terminal?

A 125 kHz EM card has one factory-set ID that can be written down more than one way. EM cards are often printed with a 10-digit number, sometimes next to a second number in "facility,card" form. That form comes from 26-bit Wiegand, a common format for the data a reader sends to its controller: one parity bit, an 8-bit facility code (0–255), a 16-bit ID (0–65,535) and a trailing parity bit. eSSL's KR500M card reader, for example, lists 26-bit and 34-bit Wiegand output.

Take a card whose ID reads 0012345678 in decimal. Its last 24 bits give facility 188 and card 24910. A supplier who prints "0012345678" and a terminal that shows "188,24910" describe the same card, yet on paper they disagree, and a whole batch gets called "not matching".

The fix: enrol one sample on your terminal, photograph the number it shows, and send that photo with the order.

A note on Wiegand: if you are adding a reader to an existing door controller or attendance panel, rather than only buying cards, the reader's output format matters as much as the card. Many panels take Wiegand 26 or Wiegand 34, and the reader must send the format the panel expects, or the same card arrives as a different number. In our catalogue the QR code and RFID card reader IDTS-QR-36 reads EM or MIFARE cards and outputs Wiegand 26/34, RS232, RS485 or TTL, and for vehicle gates the UHF card reader ID-UCR-RD901M outputs Wiegand 26/34 or RS485. Set reader and panel to the same format and enrol one card end to end before fitting the rest.

Numbering approachHow it worksChipsWatch for
Print the chip's own IDSupplier reads each card and prints its ID in your formatAnyFormat must match the terminal; IDs are not in sequence
Write your number in, then print itSupplier writes a chosen ID and prints the sameT5577; MIFARE only if your system reads sector dataTerminals that enrol the MIFARE UID never see a number written to a sector
Print a sequence unrelated to the chipCards run 0001, 0002 and so on; each is linked to a person at enrolmentAnyEvery card must be tapped and enrolled, and the register kept

Should the supplier encode the card or only read its UID?

For attendance and most door access the terminal needs only the card's ID, so nothing is written to the chip. Encoding matters in four cases:

  • T5577 cards set to a chosen ID.
  • MIFARE sector data for canteen wallets, hotel locks and some access systems. The layout and keys belong to the system owner, and stored-value cards should not run on default keys.
  • NFC cards carrying a link or contact record. This is what most people mean by "NFC card printing", and print and link must be checked as a pair.
  • UHF cards with the EPC your gate software expects.

In a typical hotel lock system the front-desk encoder writes room access at check-in, so the printer's job is a printed card with the chip the lock accepts. To check or enrol cards in-house, our LF USB desktop reader reads 125 kHz cards into a PC with no driver to install, and our HF desktop reader writer reads and writes 13.56 MHz cards.

Which printable cards are listed, and how is pricing quoted?

The card products below can be printed to order. Each product page shows the current list price before GST and the minimum order, which differs by product; add the cards you need to your quote list for a quotation.

ProductChip and bandProduct page notes
LF card125 kHz, EM4200 or T5577Plain white PVC, printable
HF attendance card13.56 MHz MIFAREPrintable; custom number encoding available
NFC card13.56 MHz, MIFARE or NTAGPhoto, QR code, sequential numbering
RFID keyfobLF, HF or UHFSequential serial encoding available
LF-HF dual-frequency card125 kHz + 13.56 MHzEM4200 or T55X7 with MIFARE Classic or DESFire
Printed RFID ID card13.56 MHz or 125 kHz, 760 micronsLogo, name, photo, numbering; gloss or matt
Printed UHF cardUHF EPC Gen 2One or both sides; signature strip, magstripe, hologram
HF+UHF hybrid card13.56 MHz + UHFHF side MIFARE or NTAG; full-colour print

The per-card price falls with quantity, so send quantity, chip, sides, personalisation and encoding through our bulk RFID pricing page for a quote. Turnaround depends on artwork approval, print method and chip stock, so ask for a dated dispatch commitment with the proof.

When comparing marketplace listings for card printing, check what the quoted per-piece rate covers: a listing may not say whether GST, numbering or encoding are included. Spec fields can also be wrong; one marketplace listing we checked tagged passive 125 kHz and 13.56 MHz cards as "Active RFID". Check the specification against a physical sample.

What artwork and data files does the card printer need?

  • Size: CR80, 85.6 × 54 mm, portrait or landscape decided before design.
  • Artwork: vector logo (PDF, AI, EPS or CDR) with fonts outlined; photos at 300 dpi; CMYK, naming any Pantone colour that must match.
  • Bleed and safe zone: as your printer specifies, with text clear of the edges and any slot-punch area.
  • Data file: one row per card (name, employee ID, department, photo file name, card number), with photos named by employee ID.
  • Back side: a return address, validity, terms of use and a signature strip if wanted.
  • Number format: the photo of your terminal showing an enrolled sample's number.
  • Approval: a signed proof for every job, and a physical sample before a large batch.

A card is lost: should you copy it or replace it?

At 125 kHz, copying a card is easy because a T5577 can carry the same ID as an EM card, and MIFARE Classic's Crypto-1 cipher was broken years ago; our RFID cloning and encryption guide covers both. A copy is the wrong answer to a lost card. The lost card still works if someone finds it, the system cannot tell copy from original, and your records now have two cards behind one person.

The authorised route is quick: block the lost card's number in the software, issue a new card with a new number, enrol it, and record the swap in your card register. That revocability is why cards make a sensible fallback to biometrics: you cannot reissue a fingerprint, but you can replace a card the same day. Our post on DPDP Rules and biometric attendance explains why employers need a working card alternative.

What can you learn from a tender that names card brands?

The Chandigarh Administration Engineering Department's tender E3/47W/138, for RFID cards and integration with the existing visitor management system at the Punjab & Haryana High Court, Sector 1, is listed on the TenderDetail aggregator with an estimate of ₹46.70 lakh and an EMD of ₹93,400. Its corrigendum table lists extensions dated 23 September, 28 September and 1 October 2026, the last moving bid submission to 5 October 2026.

The bill of quantities asks for 10,000 programmable 125 kHz cards (2 × 5,000) with an external number on each, data verification, printing and programming, a technician, and integration with an existing server described as Solus make.

  • The make lists disagree. One line names HID, Impinj and Avery Dennison; a later line names HID, Impinj and Schlage. Impinj's site describes the company as a provider of RAIN (UHF) RFID chips and readers, and Avery Dennison's RFID site describes an inlay range for the UHF, HF and NFC bands. Neither page offers a 125 kHz proximity card, so the make list may have been carried over from another document; bidders should raise it as a pre-bid query rather than guess.
  • The parts that matter are stated: 125 kHz, an external number, printer compatibility and the server the cards must work with. Those, not brand names, decide whether a card works.
  • The estimate is not a card price. It covers project management, data handling, printing, a technician and integration. Dividing ₹46.70 lakh by 10,000 gives ₹467, which says nothing about what a printed 125 kHz card costs.

For a private buyer the lesson is the same: name the reader, the frequency and the number format, add "or equivalent" if you name a make, and ask for a physical sample before the batch. Details are as listed when checked on 3 October 2026, and the official Chandigarh e-procurement documents govern. This is buying guidance, not procurement or legal advice.

Ordering printed RFID cards

India RFID Store prints and encodes RFID cards to order. Send the terminal model, a photo of an enrolled card's number and your artwork through our contact page, and we will confirm which card your reader needs and send a proof.

Frequently asked questions

Which RFID card works with an eSSL or ZKTeco attendance machine?
It depends on the card module fitted, not the brand. Terminals with an "ID card" module read 125 kHz EM-type cards, those with an "IC card" module read 13.56 MHz MIFARE cards, and "+HID" versions need HID credentials. Several models ship with any of these, so tap-test a 125 kHz and a 13.56 MHz sample on your own unit before ordering.
How can I tell whether my biometric machine reads 125 kHz or 13.56 MHz cards?
Check the spec sheet or menu for "ID card" (125 kHz) or "IC card" (13.56 MHz), then confirm with a tap test using one sample of each. If you already have a working card, hold it to an NFC-enabled Android phone with a tag-reading app: the phone cannot see 125 kHz cards, so silence points to LF.
Can the number printed on the card match the number in my attendance software?
Yes, if you fix the format first. The same chip ID can appear as a 10-digit number or as a facility code and card number taken from 26-bit Wiegand. Enrol one sample on your terminal, photograph the number it shows, and have the supplier print every card in exactly that format.
What is the bulk price of printed RFID cards in India?
Each card listing on our store shows its current list price before GST and its minimum order; add the cards to your quote list to request a quotation. The per-card price for larger orders depends on quantity, chip, print sides, personalisation and encoding, and is quoted through the bulk pricing page.
Is it safe to copy a lost RFID card?
No. A copy carries the same ID as the lost card, so the lost card keeps working if someone finds it and the system cannot tell the two apart. Block the lost card's number in the software, issue a new card with a new number, enrol it, and record the replacement in your card register.
What is NFC card printing?
NFC card printing combines a printed PVC card with a 13.56 MHz NFC chip, usually an NTAG, that a smartphone can read. The chip is encoded with a link or contact record, so the job is printing plus encoding, and each card's link should be tested against its print before dispatch.
Can I order RFID card printing online instead of from a shop near me?
Yes. Card printing does not need a counter visit. Send the reader details, a photo of an enrolled card's number, your artwork and the data file, approve a proof, and the cards are shipped to you. Ask for a physical sample first if the batch is large or the terminal is unusual.
Which key fob works with an eSSL or ZKTeco machine?
The same rule as for cards: a fob works only if its chip matches the terminal's card module. Use a 125 kHz EM fob such as the LF keyfob on "ID card" terminals and a 13.56 MHz MIFARE fob such as the HF version of the RKT keyfob on "IC card" terminals, and tap-test one before ordering in volume.
