RFID powers everything from your office access card to Amazon's warehouse automation. But how does it actually work? This beginner's guide explains RFID technology in plain language — no engineering background required.

The Three Components of Every RFID System

1. The RFID Tag

An RFID tag is a tiny electronic device consisting of:

  • An IC (chip) — stores the tag's unique ID (EPC number) and any additional data
  • An antenna — a coil or printed antenna that sends and receives radio signals
  • A substrate — the material the chip and antenna are printed/mounted on (PET film, PVC, ABS plastic, ceramic, etc.)

Passive tags (no battery) are powered entirely by the reader's radio field. Active tags have their own battery for longer range.

2. The RFID Reader

The reader (also called an interrogator) is the device that communicates with tags. It:

  • Emits a continuous radio frequency field from its antenna
  • Detects responding tags within range
  • Decodes and forwards the tag data to connected software (via USB, Ethernet, WiFi, etc.)

Readers range from desktop USB units (for encoding tags) to 4-port fixed readers covering a 12-metre dock door portal.

3. The Middleware/Software

Raw tag reads (strings of hex data) must be processed by software that maps EPC numbers to product records in your WMS, ERP, or database. This is the "intelligence" layer that makes RFID useful for your business.

The RFID Read Process — Step by Step

  1. The reader powers up and emits a continuous UHF radio signal (at 865–868 MHz in India)
  2. When a passive tag enters the field, the antenna harvests enough energy to power the chip
  3. The chip uses "backscatter modulation" — it reflects the reader's signal back with its stored data encoded
  4. The reader's receiver detects the reflected signal and decodes the EPC number
  5. The EPC is passed to middleware software via TCP/IP or USB
  6. The software looks up the EPC in the product database and records the event (time, location, action)

How Anti-Collision Works (Reading Multiple Tags)

When many tags are in the field simultaneously, they could interfere with each other. RFID uses an "anti-collision protocol" (EPC Gen 2 uses "Slotted ALOHA") where tags randomly choose a time slot to respond in. The reader manages this process, cycling through tags until all have been read. Modern UHF readers can read 1,000+ tags per second using this method.

Frequency and Physics

RFID frequencies behave differently in various environments:

  • UHF (865 MHz) — Long range, affected by water and metal. Best for open warehouse environments.
  • HF (13.56 MHz) — Short range, performs better near water. Best for access cards and wristbands.
  • LF (125 kHz) — Very short range, most tolerant of metal. Used for animal tags and vehicle immobilisers.

Real-World Example: Warehouse Receiving

  1. Supplier ships boxes with RFID labels (UHF inlays)
  2. At your dock door, a 4-port RFID reader with two antennas scans every box as the pallet moves through
  3. In 3 seconds, 48 items are identified and matched against the purchase order in your WMS
  4. Discrepancies are flagged automatically — no manual counting needed

Ready to implement RFID in your business? Explore our warehouse RFID solutions or speak with our team.

Frequently asked questions

How much does a basic RFID system cost in India?

A basic passive UHF setup typically starts from around Rs 15,000-40,000 for a desktop USB reader used to encode tags, while plain white UHF labels start from roughly Rs 8-15 each depending on volume. A 4-port fixed reader with antennas for a dock door portal usually runs Rs 1.5-3 lakh, before middleware.

How do I write my own product number onto an RFID tag?

Use a desktop USB reader and its encoding software to write your number into the tag's EPC memory bank, then lock that bank so it cannot be overwritten. Most Indian users encode a GS1 SGTIN built from their company prefix, or a simple sequential serial if tags never leave their own facility.

What is the difference between RFID and barcode scanning?

RFID needs no line of sight, so one reader can identify hundreds of tags inside a sealed carton in seconds, whereas a barcode must be individually aimed at and scanned. Barcodes are free to print, while each RFID tag costs a few rupees, so RFID pays off where counting labour dominates.

Will UHF RFID tags bought from the US or Europe work in India?

Yes, because EPC Gen 2 (ISO 18000-63) is a global standard, so any Gen 2 tag will respond to an Indian reader. However, inlay antennas are tuned by region, and US-tuned 902-928 MHz inlays can lose a noticeable share of their range on the Indian band, so ask for global or EU/India-tuned inlays.

Do I need a WPC licence to operate an RFID reader in India?

No licence is needed for 865-867 MHz UHF RFID, which WPC has de-licensed for indoor and outdoor use within the notified power limits (1 W transmit / 4 W ERP). The reader itself must hold WPC ETA approval, and India RFID Store supplies BIS and WPC certified readers configured for this band.
