IDTS-D05 Micro UHF On-Metal RFID Tag 5 mm x 4 mm PCB Disc for Tool & Instrument Tracking

The IDTS-D05 is a fingertip-sized on-metal UHF RFID tag from IDentium, built for the assets that are too small to carry a normal label. It measures just 5 mm in diameter and 4 mm thick - a black domed round disc on a dark PCB base with metal contact pads around the rim - yet it is an anti-metal design, so it keeps working when it is fixed directly to a steel or aluminium surface. Where a conventional tag would detune against metal or simply not fit, the IDTS-D05 gives small tools, gauges and fittings a permanent, machine-readable identity.

Key Specifications

• SKU: IDTS-D05 (IDentium / India RFID Store)
• Product type: UHF on-metal (anti-metal) RFID tag
• Category: PCB and Ceramic Tags
• Frequency: 860-960 MHz (global UHF band); India operates in the 865-867 MHz de-licensed band
• Protocol: ISO18000-6C
• Chip: U8 (as specified)
• EPC memory: 128 bits
• TID memory: 96 bits
• User memory: none
• Read distance: approx. 0.5 m on metal
• Anti-metal: Yes - designed for mounting on metal surfaces
• Material / substrate: PCB
• Shape: Round disc
• Diameter: 5 mm (outer diameter, not a hole)
• Thickness: 4 mm (measured at the highest point of the dome)
• Colour: Black
• Mounting hole: None
• Operating temperature: -20 C to +150 C

Applications

• Tool cribs and workshops - issue and return tracking for spanners, sockets, drill chucks and other small hand tools where a large tag would foul the grip
• Calibration and quality labs - identifying micrometers, vernier gauges, dial indicators and go/no-go gauges so calibration due-dates can be pulled up by scan
• Jigs, fixtures, dies and mould inserts - tagging small tooling on the shop floor of automotive, engineering and general manufacturing units
• Utilities and process plants - marking small valves, couplings, flanged fittings and pipe accessories for inspection rounds
• IT asset audits - labelling server rails, rack accessories, network modules, docks and other small metal hardware during annual verification
• Pharma and manufacturing spares - identifying change parts, nozzles, punches and small stainless fittings held in MRO stores
• Railway and maintenance depots - tagging small metal components and repairable spares that move between stores and the workbench

Why Choose This Tag

• Genuinely miniature. At 5 mm across and 4 mm thick, it goes on assets that simply cannot host a 20 mm or 30 mm tag - the smallest tools, gauges and fittings in your register.
• Built for metal. This is an anti-metal construction, so performance on a steel or aluminium body is designed in rather than compromised - approx. 0.5 m on metal from a tag this size.
• Wide temperature window. A rated range of -20 C to +150 C suits tooling and components that see hot processes as well as cold stores.
• Standards-based and readable with your existing kit. ISO18000-6C with 128-bit EPC and a 96-bit TID means it works with standard UHF handhelds and fixed readers, and the factory-programmed TID gives every unit a unique reference.
• Supported locally. Supplied and backed in India by India RFID Store under the IDentium / IDTS house brand, with support for encoding and deployment questions.

Read range is a typical figure and will vary with the reader, antenna, output power, the mounting surface and the surrounding environment. We recommend a short on-site trial on your own assets before bulk rollout.
