Blank UHF RFID Label Roll, 100 × 150 mm (4 × 6 in), Shipping Size
Blank, printable UHF RFID labels in the 100 × 150 mm (4 × 6 in) shipping-label size, supplied on a roll for thermal-transfer RFID printers. Print the carton or pallet label and encode the chip in one pass; the inlay and chip are confirmed at order.
Price on request
Min. order 500 piecesThe final price for your quantity is confirmed in the quote
- 7-day replacement · 1-year warranty against manufacturing defects
- Blue Dart next-day delivery
Key features
- 100 × 150 mm (4 × 6 in): the standard carton and shipping-label size
- 865–868 MHz, ISO 18000-6C / EPC Gen2 inlay, confirmed at order
- Coated-paper face for thermal-transfer printing; permanent adhesive, typical for the class
- Roll on a 3-inch core, typical for the class; labels per roll confirmed at order
- Printed and encoded on 4-inch RFID printers such as the iX4R after calibration
- Frequency
- 865–868 MHz (India UHF band)
- Protocol
- ISO 18000-6C / EPC Gen2
- Inlay / chip
- UHF inlay sized for the label; chip confirmed at order
Overview
A shipping label with a chip in it
The 100 × 150 mm (4 × 6 in) size is the standard carton and shipping label, so a UHF inlay in it lets the same label that carries the barcode and address also carry an EPC that a dock-door reader counts as the pallet goes through. Supplied blank on a roll, the labels are printed and encoded in one pass on a 4-inch RFID printer such as the iX4R industrial printer (104 mm print width), using a wax-resin ribbon; for the IT4RL desktop printer, we confirm the label width it takes before quoting.
Inlay, chip and printer set-up
The inlay inside the label is chosen for the label size and your reading distance, and the chip is confirmed at order, so the EPC memory and read performance are stated in your quotation rather than here. Before the first print run the printer is calibrated to the label pitch and the inlay position, which the printer manual covers; we supply the inlay position with the roll. For labels that go onto metal cages or drums, see on-metal labels instead, since a paper label on metal will not read. The smaller 100 × 50 mm roll suits case and shelf labels.
Ordering
Labels follow the consumables rule: minimum order 500 pcs. Request a quote with the printer model, the reading distance you need and the quantity; other sizes and pre-printed artwork are quoted on request. Browse the other UHF labels and inlays for sizes already listed with prices.
Where to use the Blank UHF RFID Label Roll, 100 × 150 mm (4 × 6 in), Shipping Size
- Carton and case labels
- Pallet labels
- Shipping and dispatch
- Warehouse receiving
- Returns and reverse logistics
Specifications
Datasheet (PDF)| Label size | 100 × 150 mm (4 × 6 in)See this size at actual size → |
|---|---|
| Frequency | 865–868 MHz (India UHF band) |
| Protocol | ISO 18000-6C / EPC Gen2 |
| Inlay / chip | UHF inlay sized for the label; chip confirmed at order |
| Face | Coated paper for thermal-transfer printing, typical for the class |
| Adhesive | Permanent acrylic, typical for the class |
| Core | 3 inch (76 mm), typical for the class |
| Labels per roll | Confirmed at order |
| Printing | Thermal-transfer RFID printers after label calibration |
Frequently asked questions
Which chip is in the label?
Can I print them on my existing barcode printer?
What is the minimum order?
