UHF RFID Pallet Tag IDTS-UPT (128 × 19 mm)
A slim 128 × 19 mm UHF hard tag for tracking wooden and plastic pallets at dock doors and gates. Built for non-metal surfaces, with an omni-directional Monza 4E chip and up to 12 m range at 2 W ERP.
₹45
per piece + 18% GST
Minimum order: 500 pieces · the final price for your quantity is confirmed in the quote
View datasheet PDF · 173 KB- 7-day replacement · 1-year warranty against manufacturing defects
- Blue Dart next-day delivery
- Samples ₹250 (1–2 pcs, incl. shipping) · request
Key features
- Long-range off-metal tag for wooden and plastic pallets
- Impinj Monza 4E with True3D dual antenna ports for omni-directional reads
- Up to 12 m at 2 W ERP; up to 15 m at 4 W ERP
- 496-bit EPC, 128-bit user memory, −14.6 dBm write sensitivity
- Industrial ABS/PC housing; drop and stress tested
- Option to add a barcode label on the front
- Frequency
- 840–960 MHz
- Chip
- Impinj Monza 4E (other chips on request)
- Read range
- Up to 12 m at 2 W ERP; up to 15 m at 4 W ERP
- Operating temperature
- −25 °C to +85 °C
Overview
A long-range UHF RFID pallet tag for non-metal pallets
The UPT is a 128 × 19 × 6 mm bar tag made for pallets with wooden, plastic or other non-metal surfaces. Its long, slim shape fits along the side of a pallet block or deck board, and the ABS/PC housing has passed drop and stress tests. It is not meant for direct mounting on steel; for metal cages and racking, choose a tag from our on-metal range.
Why the chip matters for pallets
Pallets reach a dock-door reader at every angle. The Impinj Monza 4E uses True3D, with two antenna ports that make a compact tag omni-directional, which improves read reliability when a pallet arrives turned. Custom EPC plus TID backscatter speeds up tag authentication, and a write sensitivity of −14.6 dBm helps when you commission and encode tags in bulk. The 496-bit EPC leaves room for longer identifiers; see our EPC encoding guide.
Range and labelling
Expect up to 12 m at 2 W ERP, the limit for readers on India’s 865–868 MHz band (15 m is quoted at 4 W ERP). A barcoded label can be added on the front, so the same pallet can be scanned by RFID at the dock and by barcode where no reader is installed. For dock-door layouts, read our guide to RFID in logistics and supply chain.
Typical applications
- Pallet tracking
- Dock-door verification
- Warehouse put-away
- Pallet pooling
- Pallet returns
Specifications
Datasheet (PDF)| Model | IDTS-UPT |
|---|---|
| Frequency | 840–960 MHz |
| Chip | Impinj Monza 4E (other chips on request) |
| Memory | EPC up to 496 bits; user memory 128 bits |
| Write sensitivity | −14.6 dBm |
| Data retention | 50 years |
| Write endurance | 100,000 cycles |
| Read range | Up to 12 m at 2 W ERP; up to 15 m at 4 W ERP |
| Dimensions | 128 × 19 × 6 mm |
| Weight | 13 g |
| Material | ABS/PC |
| Colour | White, grey, black, orange or blue |
| Printing | Laser engraving, marking or polyester label |
| Mounting surface | Non-metal (off-metal tag) |
| Operating temperature | −25 °C to +85 °C |
| Storage temperature | −25 °C to +65 °C |
| Operating mode | Passive (no battery) |
| Tests | Stress test and drop test passed |
