UHF RFID Windshield Label, Full-Colour Printed (110 × 40 mm)
₹25 + GST
Min. order 500 pcs
Model IDTS-UWTPIdentiumIn Stock
Printed UHF Windshield Tag
A flexible, tamper-proof UHF RFID tag that fixes inside a vehicle windshield and carries a printed serial number and barcode, for hands-free boom-barrier access at societies, campuses and car parks.
₹25
per piece + 18% GST
Minimum order: 500 pieces · the final price for your quantity is confirmed in the quote
View datasheet PDF · 183 KB- 7-day replacement · 1-year warranty against manufacturing defects
- Blue Dart next-day delivery
- Samples ₹250 (1–2 pcs, incl. shipping) · request
Key features
- Reads at over 8–10 m when fitted inside the windshield
- Tamper-proof design for a one-tag-per-vehicle policy
- Unique serial number and matching barcode printed on the front
- Custom printing with your logo and serial series
- Flexible tag, fixed with self-adhesive tape
- EPC Gen2 / ISO 18000-6C in the 865–868 MHz band
- Frequency
- 865–868 MHz
- Protocol
- EPC Gen2 / ISO 18000-6C
- Read range
- Over 8–10 m (fitted inside the windshield)
Overview
How the IDTS-UWTP windshield RFID tag works at the gate
The tag is stuck on the inside of the windshield, and a UHF reader at the lane reads it through the glass while the driver stays seated. Fitted that way it reads at over 8–10 m, which gives the barrier controller time to check the tag and lift the boom as the car rolls up, rather than after it stops.
Printed for issuing and record-keeping
Every tag carries a unique serial number and the matching barcode on its face. The admin office scans the barcode to link a tag to a flat number, employee ID or registration number without typing, and a guard can read the printed number if a vehicle needs a manual check. Tags can also be printed with your society or company logo.
Tamper-proof by design
The tamper-proof construction is meant to stop one tag being shared between cars, so it suits gates that work on one vehicle, one tag. When a resident or employee changes vehicles, issue a new tag and retire the old serial in your software.
Fitting tips
- Clean the inside of the glass with isopropyl alcohol and let it dry.
- Fit the tag near the top of the windshield, behind the rear-view mirror, unless your lane design calls for another spot.
- Keep clear of metallised sun-control film and heated-glass elements, which block UHF signals.
- Press the adhesive down firmly before the first read.
For the lane itself, look at UHF readers with a built-in antenna in our integrated readers range, and read our guide to vehicle RFID tags in India.
Typical applications
- Boom-barrier vehicle access
- Housing society gates
- Corporate campus parking
- Monthly-pass car parks
- Factory vehicle gates
- Fleet yard entry logs
Specifications
Datasheet (PDF)| Frequency | 865–868 MHz |
|---|---|
| Protocol | EPC Gen2 / ISO 18000-6C |
| Read range | Over 8–10 m (fitted inside the windshield) |
| Mounting | Self-adhesive tape, inside the windshield |
| Construction | Flexible, tamper-proof |
| Printing | Unique serial number and barcode on the front; custom logo on request |
Frequently asked questions
What read range does the IDTS-UWTP windshield tag give?
Over 8–10 m when it is fitted inside the vehicle windshield. Actual range depends on the reader's power, where the lane antenna is mounted and the type of glass or film on the vehicle.
Where on the windshield should it be fixed?
Near the top of the glass, behind the rear-view mirror, on clean and dry glass. Avoid areas with metallised sun film or heating elements, as they block UHF signals.
Can the tags be printed with our logo and number series?
Yes. Each tag has a unique serial number and matching barcode on the front, and customised tags with your logo and serial series can be supplied. Share your artwork and numbering when you request a quote.
Can a tag be moved to another vehicle?
It is not meant to be. The tag is tamper-proof, which is what makes it suitable for one-vehicle-one-tag access rules. Issue a new tag when a vehicle is replaced.
Is this the same as a FASTag?
No. This tag is read by your own gate reader for private access control and parking. FASTags are issued by banks for highway toll payment and are a separate product.
