UHF RFID Tyre Tag ID-9050-U8 (90 × 50 mm)
A 90 × 50 mm UHF RFID tyre (tire) tag on the NXP UCODE 8/9 chip family for identifying tyres in warehouses, at dealers and retreaders, and in fleet depots. Reads at up to 8 m.
₹8
per piece + 18% GST
Minimum order: 500 pieces · the final price for your quantity is confirmed in the quote
View datasheet PDF · 177 KB- 7-day replacement · 1-year warranty against manufacturing defects
- Blue Dart next-day delivery
- Samples ₹250 (1–2 pcs, incl. shipping) · request
Key features
- 90 × 50 mm label-format tag for tyres and heavy vehicle assets
- NXP UCODE 8 / 9 / 9xe / 9xm chip, 128–496-bit EPC
- Read range up to 8 m, depending on reader, antenna and placement
- Can be supplied pre-encoded with tyre or vehicle numbers
- 860–960 MHz, covering India's 865–868 MHz band
- Chip
- NXP UCODE 8 / 9 / 9xe / 9xm
- Frequency
- 860–960 MHz (covers India's 865–868 MHz band)
- Protocol
- EPC Class 1 Gen2 / ISO 18000-6C
- Read range
- Up to 8 m (depends on reader, antenna and environment)
Overview
ID-9050-U8 UHF RFID tyre tag for stock, dealers and fleets
The ID-9050-U8 is a 90 × 50 mm UHF RFID tag for identifying tyres (tires) and other vehicle and heavy assets. It uses an NXP UCODE 8/9 family chip with 128 to 496 bits of EPC memory, depending on the variant, and reads at up to 8 m depending on the reader, antenna and environment. The large face leaves room for a printed tyre number or barcode next to the RFID inlay.
Label tag, patch or embedded: know which you need
Tyre RFID comes in three broad forms: tags built into the tyre during manufacture, patches bonded inside the tyre afterwards, and label-format tags like this one. A label tag suits identification while the tyre sits in a warehouse, dealer stockyard or retreading shop, and for fleet tyre records. If the tag has to go through curing or stay on for the tyre's road life, share your process with us before ordering so the right construction can be checked with samples. Our guide to RFID tyre tags and ISO 20909 compares the options.
Reading tyres in racks and lanes
In a tyre store, a UHF handheld reader walked along the racks counts stacked tyres without unloading them. At a depot gate or service lane, a fixed reader logs tyres as vehicles pass; read distance there depends on where the tag sits, vehicle speed and antenna placement.
Typical applications
- Tyre warehouses
- Tyre dealer stock
- Retreading shops
- Fleet tyre tracking
- Vehicle asset tagging
Specifications
Datasheet (PDF)| Model | ID-9050-U8 |
|---|---|
| Dimensions | 90 × 50 mm |
| Chip | NXP UCODE 8 / 9 / 9xe / 9xm |
| Memory | 128–496-bit EPC (depends on chip) |
| Frequency | 860–960 MHz (covers India's 865–868 MHz band) |
| Protocol | EPC Class 1 Gen2 / ISO 18000-6C |
| Read range | Up to 8 m (depends on reader, antenna and environment) |
| Material | Flexible thin substrate, RoHS-compliant |
| Compatible with | Standard UHF RFID readers and printers |
Frequently asked questions
Can the ID-9050-U8 be cured into a tyre?
What read range does the tyre tag give?
Can tags be pre-encoded with tyre or vehicle numbers?
Which chip variant should I choose?
