UHF RFID Windshield Label, Full-Colour Printed (110 × 40 mm)
₹25 + GST
Min. order 500 pcs
_2wiTJA.webp)
Model IDTS-UTWTH3IdentiumIn Stock
UHF Tamper Proof Windshield Label
A self-adhesive UHF RFID windshield label that is fixed inside the windscreen and cannot be moved to another vehicle intact. For parking operators, gated campuses, factories and transport yards identifying vehicles at a boom barrier.
₹25
per piece + 18% GST
Minimum order: 500 pieces · the final price for your quantity is confirmed in the quote
View datasheet PDF · 174 KB- 7-day replacement · 1-year warranty against manufacturing defects
- Blue Dart next-day delivery
- Samples ₹250 (1–2 pcs, incl. shipping) · request
Key features
- Tamper-proof: cannot be peeled off and refitted intact
- Reads over 8–10 m when fixed inside the windshield
- Unique serial number and matching barcode printed on the front
- Flexible label with self-adhesive tape for quick fitting
- Hands-free vehicle identification at barriers and lanes
- Read range
- Over 8–10 m when fixed inside the windshield
Overview
How the UHF tamper-proof windshield label works
The label sticks to the inside of the windscreen with its self-adhesive tape. A UHF reader at the gate picks it up from over 8–10 m away, so the barrier can start opening before the vehicle stops. Because the label is tamper-proof, peeling it off damages it, so a tag issued to one car cannot be moved to another intact.
Issuing labels to vehicles
Every label carries a unique serial number and a matching barcode on the front. At the issue desk, scan the barcode to register the label against the vehicle number and owner in your parking or access software, then fit it on the glass. No manual typing is needed, which keeps errors out of the vehicle register.
Where it is used
- Housing societies, corporate campuses and hospitals running boom barriers
- Factory gates and transport yards logging trucks in and out
- Toll, transport and vehicle identification systems
Fitting and reader set-up
Clean and dry the glass, then fit the label high on the windscreen, usually behind the rear-view mirror. Some windscreens have metallised heat-reflective coatings that block UHF signals, so test one such vehicle before a full rollout. At the lane, a long-range integrated UHF reader mounted on a pole facing the traffic is the usual choice. If you want your logo printed on the face, see the Printed UHF Windshield Tag.
Typical applications
- Parking access control
- Housing society gates
- Factory vehicle gates
- Electronic toll collection
- Fleet and transport yards
- Vehicle security checks
Specifications
Datasheet (PDF)| Type | Flexible UHF RFID windshield label |
|---|---|
| Read range | Over 8–10 m when fixed inside the windshield |
| Mounting | Self-adhesive tape, inside of the windshield |
| Tamper protection | Tamper-proof; cannot be removed and refitted intact |
| Printing | Unique serial number and barcode on the front |
Frequently asked questions
What is the read range of this windshield label?
It reads at over 8–10 m when fixed on the inside of a vehicle's windshield. Actual range depends on the reader's power, the antenna position at the lane and the type of glass; heat-reflective coated windscreens can reduce or block reads.
Can the label be moved to another vehicle?
No. It is a tamper-proof label fixed with self-adhesive tape, and removing it from the glass damages it, so a label issued to one vehicle cannot be transferred intact. This keeps one tag tied to one vehicle in your access records.
Is this the same as a FASTag?
No. FASTag is issued through banks for national highway toll payment. This label is for your own parking, campus or yard system: it uses the same UHF RFID technology, but the tag numbers are registered and managed in your software.
Which reader do I need at the gate?
Use a long-range UHF reader, typically an integrated reader with a built-in antenna on a pole facing incoming traffic, connected to your boom barrier controller or access software. The reader sends the tag number and your software decides whether to open the barrier.
Do the labels come with serial numbers printed?
Yes. Each label has a unique serial number and a matching barcode printed on the front, so it can be registered against a vehicle by scanning at the issue desk before fitting.
