UHF RFID LED Cable Label ID-4111-KX (41 × 11 mm)
A UHF RFID cable label with an LED, built on the KX2005XBL chip, that gives each cable or wire its own electronic ID and helps a technician pick out the right one in a crowded rack or tray.
₹15
per piece + 18% GST
Minimum order: 500 pieces · the final price for your quantity is confirmed in the quote
View datasheet PDF · 171 KB- 7-day replacement · 1-year warranty against manufacturing defects
- Blue Dart next-day delivery
- Samples ₹250 (1–2 pcs, incl. shipping) · request
Key features
- LED on the label to help locate the tagged cable
- KX2005XBL chip with 96–240-bit EPC and 1312-bit user memory
- 41 × 11 mm antenna on a 95 × 30 mm die-cut label
- EPC Class 1 Gen2 / ISO 18000-6C at 860–960 MHz
- Read range listed up to 6 m, depending on reader and setup
- Chip
- KX2005XBL
- Frequency
- 860–960 MHz (covers India’s 865–868 MHz band)
- Protocol
- EPC Class 1 Gen2 / ISO 18000-6C
- Indicator
- LED
Overview
UHF RFID LED label for finding the right cable
In a patch panel or cable tray, a printed marker only tells you what a cable is once you have found it. The ID-4111-KX gives each cable a UHF RFID identity and adds an LED, so a technician with a UHF reader can identify a cable electronically and use the light to pick it out from its neighbours. The reader drives the LED, so confirm that your handheld or software can trigger it before ordering in volume.
Why UHF for cable labelling
UHF reads at a distance and can pick up many tags in one pass, so a handheld can sweep a whole rack or tray instead of touching each label. The read range is listed up to 6 m; among dense bundles and metal racks the working distance is shorter. The KX2005XBL chip carries a 96–240-bit EPC plus 1312 bits of user memory, enough for a cable reference, circuit ID or termination point stored on the label itself.
Size and fitting
The 41 × 11 mm antenna sits on a larger 95 × 30 mm die-cut label, so check that footprint against the space on your cables and panels before ordering. Keep the antenna area off bare metal trays and enclosures, because metal directly behind a standard UHF label reduces read performance.
For one-at-a-time checks with a phone, compare the ID-7556 NFC LED cable label. More formats are in RFID specialty labels.
Typical applications
- Data centre patching
- Electrical panel wiring
- Telecom racks
- Cable trays
- Plant room cabling
- Utility cable records
Specifications
Datasheet (PDF)| Model | ID-4111-KX |
|---|---|
| Chip | KX2005XBL |
| Memory | EPC 96–240 bits; user 1312 bits |
| Frequency | 860–960 MHz (covers India’s 865–868 MHz band) |
| Protocol | EPC Class 1 Gen2 / ISO 18000-6C |
| Antenna size | 41 × 11 mm |
| Label size (die-cut) | 95 × 30 mm |
| Indicator | LED |
| Read range | Up to 6 m listed (depends on reader, antenna and environment) |
| Material | Flexible thin substrate, RoHS-compliant |
